Parameters
P260 mA Raw Input [MR 200]
Shows the raw mA input supplied by the external device.
Discrete Input Functions (P270 to P275)
Discrete inputs can be used for the following:
• Passing other information to a remote system through communications
• Backup level override
Use the parameters listed above to have discrete inputs modify the unit’s operation.
Use the following parameters to configure the discrete input itself.
See also the
Pump Control section on page 57 for a description of the MultiRanger’s
pump control algorithms, including how the discrete inputs alter its operation.
P270 Discrete Input Function
Sets how discrete signals are interpreted by the MultiRanger.
Primary Index mA input
Values Range: 0.000 to 20.00 (view only)
Primary Index Discrete input
Values
0Forced OFF
1Forced ON
2 * Normally Open – 0 (DI open), 1 (DI closed)
3 Normally Closed – 0 (DI closed), 1 (DI open)
Related • Pump Control section

Siemens MAG 6000 Specifications

General

Type	Electromagnetic Flow Meter
Nominal Diameter	DN 15 to DN 3000
Lining Material	PTFE, Hard Rubber, Polyurethane
Electrode Material	Stainless Steel, Hastelloy, Tantalum, Platinum
Flow Rate Range	0 to 12 m/s
Protection Class	IP67, IP68
Communication	HART, PROFIBUS PA, PROFIBUS DP, FOUNDATION Fieldbus
Output Signals	4 to 20 mA, Pulse/Frequency
Power Supply	24 V DC
Process Temperature Range	-40°C to +180°C (depending on lining material)
Ambient Temperature Range	-40°C to +60°C
