15
SITRANS F M
2. Technical data
MAG 3100, MAG 3100 HT and MAG 3100 P
Design (continued)
Type MAG 3100 MAG 3100 HT (High Temperature) MAG 3100 P
Electrode material • AISI 316 Ti (1.4571) • AISI 316 Ti (1.4571) Hastelloy C276 (PFA: Hastelloy C22)
•
Hastelloy C276 (PFA: Hastelloy C22) • Hastelloy C276 (PFA: Hastelloy C22)
• Platinum/iridium, • Platinum/iridium,
• Titanium • Titanium
• Tantalum • Tantalum
Grounding electrode Material as measuring electrodes: No grounding electrodes No grounding electrodes
material Exceptions - see ordering data
Terminal box (remote • Standard: Fibre glass reinforced • Stainless steel AISI 316 (1.4436) • Standard: Fibre glass reinforced
version only) polyamide • Ex ATEX (remote version only) polyamide
• Option: Stainless steel AISI 316 Stainless steel AISI 316 (1.4436) • Option: Stainless steel AISI 316
(1.4436) (1.4436)
• Ex ATEX (remote version only): • Ex ATEX (remote version only)
Stainless steel AISI 316 (1.4436) Stainless steel AISI 316 (1.4436)
Cable entries • Remote installation:
2 x M20 or 2 x ½ NPT
• Compact installation
- MAG 5000/MAG 6000: 4 x M20 or 4 x ½
"
NPT
Certificates and approvals
Conforms to PED – 97/23 EC, CRN
Material certificate On request On request Pipe and flange certificate available
EN 10204 3.1 as option
Ex approvals ATEX 2G D sensor ATEX 2G D sensor ATEX 2G D sensor
• DN 15 ... 300/(½" ... 12"): • DN 15 ... 300/(½" ... 12"): • DN 15 ... 300/(½" ... 12"):
EEx d e ia IIC T4 - T6 EEx d e ia IIC T3 - T6 EEx d e ia IIC T3 - T6
• DN 350 ... 2000/(
14
" ... 78"): Non-ATEX sensors Non-ATEX sensors
EEx e ia IIC T4 - T6 • FM Class 1, Div 2 • FM Class 1, Div 2
Non-ATEX sensors • CSA Class 1, Div 2 • CSA Class 1, Div 2
• FM Class 1, Div 2
• CSA Class 1, Div 2
Drinking water approvals EPDM lining:
• WRAS (WRc, BS6920 cold water, UK)
• ACS listed (F)
• DVGW W270 (D)
NSF/ANSI Standard 61 (Cold water, US)
• Belgaqua (B)
Mcerts (EPDM or PTFE lining with
AISI 316 Ti or Hastelloy C276 electrodes)
Custody transfer (CT) Cold water - DANAK TS 22.36.001 Heat meter pattern approval - OIML R 75 Cold water - DANAK TS 22.36.001
(
≤
DN2000) Cold water pattern approval PTB (Denmark) Cold water pattern approval PTB
(MAG 5000/6000 CT) (Germany) Hot water pattern approval - PTB (Germany)
Heat meter pattern approval - OIML R 75 (Germany) Heat meter pattern approval - OIML R 75
(Denmark) (Denmark)
Hot water pattern approval - PTB Hot water pattern approval - PTB
(Germany) (Germany)
Other media than water pattern approval - Other media than water pattern approval -
OIML R 117 (Denmark) OIML R 117 (Denmark)
2.3 Sensor MAG 3100, MAG 3100 HT and MAG 3100 P (continued)
