SIB3 LEDs
LED Locations
The SIB3 has several LEDs that indicate useful information about the operating status of
various interfaces.
I
2
C-Pullup
Active LEDs
3
2
1
0
PCI Slot LEDs
Reset
I/O Connector
DI Mode
Switch
(Set to Mode 2)
CAN
Bridge
LEDs
Power LEDs
Internal
Ethernet
to SNECON
LEDs
CAC3
I
2
C LEDs
Figure 2-14 SIB3 LEDs and Switches
Electronic Compartment Component Descriptions and Maintenance Procedures
2.3 System Controller Version 2.1 (SYSCON2.1)
Maxum II Reference Manual
Manual, 7/2017, 2000596-001 37
