Siemens Maxum II Reference Manual

Status
LEDs
Access hole for mounting
screw for Temp Setpoint modules
Ignite Signal/
Igniter Power
Location
ID Switch
RTD Temp Control Input
Flame Sense and
Filament Detector Input
Signal Cable
from Detector
Mezzanine
Module
Mounting
Location
Figure 2-26 Base3DPM With Mezzanine Module
Part Number
The Base3 DPM (Part Number A5E02645925001) is shipped with current analyzers. It can
be used as a replacement part for earlier DPMs in Maxum I analyzers using an adapter, part
number A5E34938458001.
Electronic Compartment Component Descriptions and Maintenance Procedures
2.5 Detector Personality Modules
Maxum II Reference Manual
62 Manual, 7/2017, 2000596-001

Siemens Maxum II Specifications

General

Category	Gas Chromatograph
Measurement Principle	Gas Chromatography
Communication Protocols	Modbus, Ethernet, Profibus
Operating Temperature	-20°C to 55°C
Power Supply	24 VDC or 100-240 VAC
Mounting	rack mount
Applications	Refinery, chemical, petrochemical, natural gas
Detectors	Thermal Conductivity Detector (TCD), Flame Ionization Detector (FID)
Sample Inlets	Multiple
Dimensions	Varies by configuration (e.g., 19" rack mount)
