MICROMASTER 420 Reference Manual
Issue A1
71
4.2.5 Circuit Breakers
Table 4-4 Recommended Circuit Breakers (230 V Single-phase)
,QYHUWHU
3RZHU
N:
,QYHUWHU
3RZHUKS
,QYHUWHU)LOWHU
&ODVV
)UDPH
6L]H
,QYHUWHU2UGHU1XPEHU
0/)%
0LQLDWXUH
&LUFXLW
%UHDNHUV
0.12 0.16 Unfiltered FS A 6SE6420-2UC11-2AA0 3RV1021-1CA10
0.25 0.33 Unfiltered FS A 6SE6420-2UC12-5AA0 3RV1021-1EA10
0.37 0.50 Unfiltered FS A 6SE6420-2UC13-7AA0 3RV1021-1FA10
0.55 0.75 Unfiltered FS A 6SE6420-2UC15-5AA0 3RV1021-1HA10
0.75 1.00 Unfiltered FS A 6SE6420-2UC17-5AA0 3RV1021-1JA10
1.10 1.50 Unfiltered FS B 6SE6420-2UC21-1BA0 3RV1021-1KA10
1.50 2.00 Unfiltered FS B 6SE6420-2UC21-5BA0 3RV1021-4AA10
2.20 3.00 Unfiltered FS B 6SE6420-2UC22-2BA0 3RV1021-4CA10
3.00 4.00 Unfiltered FS C 6SE6420-2UC23-0CA0 3RV1031-4EA10
0.12 0.16 A FS A 6SE6420-2AB11-2AA0 3RV1021-1CA10
0.25 0.33 A FS A 6SE6420-2AB12-5AA0 3RV1021-1EA10
0.37 0.50 A FS A 6SE6420-2AB13-7AA0 3RV1021-1FA10
0.55 0.75 A FS A 6SE6420-2AB15-5AA0 3RV1021-1HA10
0.75 1.00 A FS A 6SE6420-2AB17-5AA0 3RV1021-1JA10
1.10 1.50 A FS B 6SE6420-2AB21-1BA0 3RV1021-1KA10
1.50 2.00 A FS B 6SE6420-2AB21-5BA0 3RV1021-4AA10
2.20 3.00 A FS B 6SE6420-2AB22-2BA0 3RV1021-4CA10
3.00 4.00 A FS C 6SE6420-2AB23-0CA0 3RV1031-4EA10
Table 4-5 Recommended Circuit Breakers (230 V Three-phase)
,QYHUWHU
3RZHU
N:
,QYHUWHU
3RZHUKS
,QYHUWHU)LOWHU
&ODVV
)UDPH
6L]H
,QYHUWHU2UGHU1XPEHU
0/)%
0LQLDWXUH
&LUFXLW
%UHDNHUV
0.12 0.16 Unfiltered FS A 6SE6420-2UC11-2AA0 3RV1021-1AA10
0.25 0.33 Unfiltered FS A 6SE6420-2UC12-5AA0 3RV1021-1CA10
0.37 0.50 Unfiltered FS A 6SE6420-2UC13-7AA0 3RV1021-1DA10
0.55 0.75 Unfiltered FS A 6SE6420-2UC15-5AA0 3RV1021-1FA10
0.75 1.00 Unfiltered FS A 6SE6420-2UC17-5AA0 3RV1021-1GA10
1.10 1.50 Unfiltered FS B 6SE6420-2UC21-1BA0 3RV1021-1HA10
1.50 2.00 Unfiltered FS B 6SE6420-2UC21-5BA0 3RV1021-1JA10
2.20 3.00 Unfiltered FS B 6SE6420-2UC22-2BA0 3RV1021-1KA10
3.00 4.00 Unfiltered FS C 6SE6420-2UC23-0CA0 3RV1021-4BA10
4.00 5.00 Unfiltered FS C 6SE6420-2UC24-0CA0 3RV1021-4CA10
5.50 7.50 Unfiltered FS C 6SE6420-2UC25-5CA0 3RV1031-4FA10
3.00 4.00 A FS C 6SE6420-2AC23-0CA0 3RV1021-4BA10
4.00 5.00 A FS C 6SE6420-2AC24-0CA0 3RV1021-4CA10
5.50 7.50 A FS C 6SE6420-2AC25-5CA0 3RV1031-4FA10
