Applications
Mounting Details
6 mm (0.25”) dia.
hole for ¼ -20 nut
and bolt
or drill and tap,
four holes on
114 mm (4.5“) BCD
6 mm (0.25”) dia. hole for
¼ -20 bolt on 114 mm (4.5”)
BCD, four places
9
5 mm (3.75”) dia.
probe clearance
hole
133 mm
(5.25”) O.D.
2” NSPL
25mm
(1”)
Mounting Flange
APPLICABLE TO ALL PROBES
EXCEPT MSP-1 AND MSP-9
