A5E32268616 Pointek ULS200 – QUICK START MANUAL Page EN-3
mmmmm
English
Specifications
Environmental
• location: indoor/outdoor
• altitude: 2000 m max
• ambient temperature: - 40 to 60 °C (- 40 to 140 °F)
• * - 20 °C (-5 °F) if metal mounting
• relative humidity: suitable for outdoor (Type 6/NEMA 6/IP67 enclosure)
• installation category: II
• pollution degree: 4
Process Pressure
• 0.5 bar (7.25 psi) max.
Switching Range
• liquids: 0.25 to 5 m (0.8 to16.4 ft)
• solids: 0.25 to 3 m (0.8 to 9.8 ft)
Memory
• non-volatile EEPROM
Programming
•2 keys
Temperature Compensation
• built-in to compensate over the operating range
Display
•LCD
• three 9 mm (0.35") digits for reading of distance between sensor face and material,
multi-segment graphic for operation status
AC Version DC Version
Power Power
• 100 to 230 V AC, + 15%, 50/60 Hz, 12 VA
(5W) max.
18 to 30 V DC, 3 W
1
1.
See
Power
on page 8, for minimum supply voltage required with DC version.
Fuse Output
• Slow-Blow, 0.25 A, 250 V AC • repeatability: 0.25 % of full range
Output
• resolution: 3 mm (0.1")
• repeatability: 0.25% of full range •relay
2
: 2 Form C (SPDT)
contacts, rated max. 5 A
@ 30 V DC non-inductive;
min. 10 mA @ 5 V DC
• resolution: 3 mm (0.1") OR
•relay
2
: 2 Form C (SPDT) contacts,
rated max. 5A @ 250 V AC
/ 30 V DC non-inductive;
min. 10 mA @ 5 V
DC
2.
See
Interface
on page 7, for operation up to 48 V DC.
• transistor: 2 transistor
switches, rated
100 mA maximum at
48 V DC
