Siemens MOBILETT Plus HP Installation Instructions

Installation 2 - 13
Siemens AG SPR8-220.031.04 Page 13 of 30 MOBILETT Plus/ -E/ -HP
Medical Solutions Rev. 04 09.03 CS PS 24
24. Put shrinking tubes (66 11 107, cut to 20 mm length) over each of the newly
soldered cables (see pos. 3 / Fig. 13) and shrink them (pos. 4 / Fig. 13).
25. Place two cable ties (2.5x100mm) according to pos. 1 / Fig. 14.
MOB00461
Fig. 14 Placing of cable ties
1
