MOBILETT Plus / - E/ - M SPR8-215.898.01 Page 4 of 6 Siemens-Elema AB
Rev. 05 01.02 SPS-UD Solna, Sweden
1 - 4 General
Protective measures when working on the capacitor bank 1
• System OFF.
• Disconnect the mains cable.
• Remove the system upper cover.
• Discharge the capacitor bank with S10 (D7) (Fig. 1).
• Wait 5 minutes; then remove the left, right and front covers.
Fig. 1 Fig. 2
Comply with the information given in this section, before opening the system.
Never work with the system open if the capacitor is charging or
has just been charged.
The capacitor bank may still be charged even if the system is
switched OFF and the line voltage cable is disconnected.
Life-threatening electric shock hazard exists.
Consult the information in this chapter.
CAPNEG
MOB00493
CAPPOS
