Page EN-8 MultiRanger – QUICK START MANUAL 7ML19985QD82
mmmmm
English
Quick Start Parameters
Notes:
• P000 locks the unit, The unlocking value is 1954. All other values lock the unit.
• Defaults are shown with an *
P001 Operation: Sets the type of
measurement required for the application.
Primary
Index
Standard Mode Dual Point Mode
Global Transducer
Values
0Out-of-service
1 Material Level
2Space
3 * Distance (transducer to material)
4 DPD – dual point difference
5 DPA – dual point average
6 OCM – open channel flow rate
7 Pump Totalizer
P002: Material: Measures material type.
Liquid, may involve solids.
Primary
Index
Standard Mode Dual Point Mode
Global Transducer
Values
1 * Liquid or horizontal solid surface
2 Solid or angled surface
P003 Maximum Process Speed:
Determines level change reaction.
Primary
Index
Transducer
Values
1 Slow (0.1 m/min)
2 * Medium (1 m/min)
3 Fast (10 m/min)
P004 Transducer: Specifies transducer.
Primary
Index
Standard Mode Dual Point Mode
Global Transducer
Values
0*
No transducer attached (preset for
Dual Point)
1ST-25
2ST-50
100 STH
101 XCT-8
102 *
XPS-10 (preset for Standard
Mode)
103 XCT-12
104 XPS-15
112 XRS-5
250 mA input
P005 Units: Specifies units used for
dimensional values.
Primary
Index
Global
Values
1*Meters
2 Centimeters
3 Millimeters
4 Feet
5Inches
P006 Empty: Distance in Units (P005) from
transducer face to process empty point.
Primary
Index
Transducer
Values
Range: 0.000 to 9999
Preset: 5.000m (or equivalent
depending on units)
Alters •P007 Span
Altered By •P005 Units
P007 Span: Sets range levels to be
measured.
Primary
Index
Level
Values
Range: 0.000 to 9999
Preset: based on Empty (P006)
Note: Please refer to the Instruction
Manual to set up inputs, alarms and
controls, communications, and other
functionality.
