Connecting cable to the reader
10.1 Routing of standard cables
RF180C communication module
Operating Instructions, 12/2012, J31069-D0177-U0
01-A6-7618
61
Table 10- 3
Connecting cable M12 ↔ sub-D 9-pin
M12 connector (male)
Sub-D connector (femal
e)
1
–
2
5
3
7
4
3
5
2
6
6
7
–
8
1, 8
Note:
Readers with D-sub connect
ors must be supplied with 24 VDC via
an addition
al connector
.
