Certification
6.2EMC and Environmental Type Tests
Description Test Levels
Signal Ports 5 kV (Failsafe Relay Output)
DC Power Ports
HV Impulse
AC Power Ports
5 kV
Signal Ports 2 kV
DC Power Ports 1.5 kVDC
Dielectric
Strength
AC Power Ports 2 kV
Signal Ports
DC Power Ports
AC Power Ports
± 4 kV @ 2.5 and 5 kHzFast Transient
Earth Ground Ports ± 4 kV @ 5 kHz
Signal Ports 2.5 kV Common Mode @ 1MHz
DC Power Ports
Oscillatory
AC Power Ports
2.5 kV Common Mode
1 kV Differential Mode @ 1 MHz
Radiated RFI Enclosure ports 35 V/m
Enclosure Contact ± 2 kV
± 4 kV
± 8 kV
ESD
Enclosure Air ± 4 kV
± 8 kV
± 15 kV
Environmental Type Tests
Test Description Test Levels
IEC 60068-2-1 Cold Temperature Test Ad -40 °C (-40 °F), 16 Hours
IEC 60068-2-2 Dry Heat Test Bd 85 °C (185 °F), 16 Hours
IEC 60068-2-14 Change of Temperature Test Nb 5 Cycles, -40 to 85°
C (40 to 185° F)
IEC 60068-2-30 Humidity (Damp Heat, Cyclic) Test Db 95% (non-condensing)
55 °C (131 °F), 6 Cycles
IEC 60068-2-31 Free Fall Procedure 1, 2 falls from a
height of 250 mm (9.8 in)
IEC 60068-2-78 Humidity (Damp
Heat, Steady State)
Test Cab 10 days @ 55 °C (131 °F)
and 93% Relative Humidity
IEC 60255-21-1 Vibration Level 2 (2 g @ 10 to 150 Hz)
Shock Level 2 (30 g @ 11 mS)IEC 60255-21-2
Bump Level 1 (10 g @ 16 mS)
IEC 60529 Ingress Protection IP3x
42
RUGGEDCOM RSG2488
Installation Manual, 07/2021, C79000-G8976-1048-11
