C7-613 Control System
A5E00138934-03
Preface
Purpose of this Manual
This manual provides a complete overview of the C7-613 Control System and
assistance with its installation and commissioning. The manual explains how to
install expansion modules and introduces the corresponding components.
This manual is intended for persons having the required qualifications to
commission, operate, and program the hardware product described.
Basic knowledge requirements
A general knowledge of automation systems engineering is prerequisite for
understanding the topics dealt with in this manual.
Users should also be familiar with the operation of computers or auxiliary
programming equipment similar to PCs, operating under the operating system
platform Windows 2000 or XP. Users should also be familiar with the STEP 7
standard software. For information, refer to the Programming with STEP 7
manual.
In particular when using a PLC in hazardous locations, pay attention to the
information on the safety of electronic controls in Chapter 2 and Appendix A.
Scope of Manual
This manual is applicable to the following:
Order Number
As of Version
Firmware Hardware
C7-613 6ES7 613-1CA01-0AE3 CPU V2.0.7
HMI V2.00
02
HMI-FBs
On the CD
“Configuration Tools
for SIMATIC C7-613”
6ES7613-0CA00-7AA0 V2.0
This manual describes the modules that are valid at the time the manual is issued.
A product information containing up-to-date information on the module is included
at more recent modules or modules with a newer version.
Approbation
For detailed information on approvals and standards, refer to Appendix A,
Technical data.
