Preface
v
C7-613 Control System
A5E00138934-03
The documentation package consists of five manuals, a Getting Started manual,
and an instruction list.
S7 300 CPU Data: CPU 31xC and CPU 31x
Manual
S7 300 CPU 31xC
Technological functions
Manual
S7 300 Installation: CPU 31xC and CPU 31x
Manual
S7 300 module data
Manual
Instruction list
CPU 31xC, CPU 31x,
IM 151-7 CPU, BM 147-1 CPU,
BM 147-2 CPU
C7-613Control System Getting Started
Description of operator input, the functions,
and the technical data of the CPU.
Description of the various technological functions:
• Positioning
• Counting
• Closed loop control
The CD contains examples of the technological
functions
Description of the configuration, installation,
wiring, networking, and commissioning of an
S7-300.
Description of functions and technicalspecifica-
tions of signal modules,power supply modules,
and interface modules
List of the CPU instruction set and the correspon-
ding execution times
List of executable blocks (OBs/SFCs/SFBs) and
the corresponding execution times.
Getting Started introduces you to the C7-613 func-
tions with operating steps and expansions of an
existing sample project.
Getting Started
C7-613Control System
Manual
Description
• Installation and wiring
• Data blocks with configuration data
• HMI functions
• Operator control
• Technical specifications of the C7-613
You are reading this manual:
Examples
