Mounting
5
Note
• When installing control and measuring devices in the Ex enclosure, keep to the instructions
in the relevant product descriptions and the technical specications in the data sheets.
• All control and measuring devices installed in the enclosure must be separately certied for
the relevant hazardous zone.
• Run the tests prescribed in the relevant national regulations for the installed control and
measuring devices.
Note
• Install and operate the wall-mounted enclosure in hazardous areas in accordance with the
specications of the EC-type examination certicate according to ATEX Directive 2014/34/EU
and these operating instructions or the standards and directives applicable in your country.
• Assembly, installation, commissioning and maintenance may only be performed by qualied
personnel.
• The devices and installed components must only be used for their intended purpose.
5.1 Transport and storage
Pack and store the enclosure for transportation or storage in a way that prevents excessive stress
on the enclosure, especially on the enclosure cover. If there is too much strain on the top cover
of the enclosure, this can damage the seal.
Do not place the enclosure on the cable entries installed in the oor to avoid damaging them.
Distributed I/O device 6DL2804-1xxxx & 6DL2804-2xxxx
Hardware Installation Manual, 11/2023, A5E42025214-AC 21
