10.2 Installation: Heating
① Heating
② Thermostat
③ Infeed terminals
Figure10-2 Distributed I/O device with installation of heating
Dimension drawings
10.2Installation: Heating
Distributed I/O device 6DL2804-1xxxx & 6DL2804-2xxxx
36 Hardware Installation Manual, 11/2023, A5E42025214-AC
