10.3 Installation: FO coupler
① FO coupler
② Terminals for power supply and distribution 24V DC
Figure10-3 Distributed I/O device with installation of FO coupler: single and redundant designs
Dimension drawings
10.3Installation: FO coupler
Distributed I/O device 6DL2804-1xxxx & 6DL2804-2xxxx
Hardware Installation Manual, 11/2023, A5E42025214-AC 37
