Siemens SIMATIC ET 200SP TM ECC 2xPWM ST User Manual

Technology module TM ECC 2xPWM ST (6FE1242-6TM10-0BB1)
Manual, 04/2018, A5E42681298B-AA
31
Configuring/address space
4
4.1
Configuring
Introduction
You can configure and parameterize the technology module SIMATIC ET 200SP TM ECC
2xPWM ST with configuration software. The functions of the technology module are
controlled and monitored by the user program.
System environment
You can use the technology module in the following system environments:
Table 4- 1 Possible applications of the technology module with PROFINET I/O
Applications
Required components
Configuration software
In your program
Distributed operation in an
S7-1500 system
• S7-1500 Automation
system
• ET 200SP Distributed I/O
System
• SIMATIC ET 200SP
TM ECC 2xPWM ST
technology module
STEP 7 (TIA Portal):
Device configuration and
parameter settings with the
hardware configuration
(HWCN)
Direct access to the control
and feedback interface
(Page 35) of the SIMATIC
ET 200SP TM ECC
2xPWM ST technology mod-
ule in the I/O data
Centralized or distributed
operation in an ET 200SP
system
• ET 200SP automation
system
• SIMATIC ET 200SP
TM ECC 2xPWM ST
technology module
STEP 7 (TIA Portal):
Device configuration and
parameter settings with the
hardware configuration
(HWCN)
Direct access to the control
and feedback interface of the
SIMATIC ET 200SP
TM ECC 2xPWM ST tech-
nology module in the I/O
data
Distributed operation in a
PROFINET controller
PROFINET controller
• ET 200SP Distributed I/O
System
• SIMATIC ET 200SP
TM ECC 2xPWM ST
technology module
Engineering system with
GSDML file
Direct access to the control
and feedback interface of the
SIMATIC ET 200SP
TM ECC 2xPWM ST tech-
nology module in the I/O
data
Hardware Support Package (HSP)
If you cannot find the SIMATIC ET 200SP TM ECC 2xPWM ST technology module in the
hardware catalog of the TIA Portal, you must install the corresponding HSP file (HSP0234
ET200SP ECC 2xPWM).
The Hardware Support Package (HSP) is available as download
(http://support.automation.siemens.com/WW/view/en/72341852) on the Internet.
