Siemens SIMATIC ET 200SP TM ECC 2xPWM ST User Manual

Configuring/address space
4.5 Control and feedback interface
Technology module TM ECC 2xPWM ST (6FE1242-6TM10-0BB1)
Manual, 04/2018, A5E42681298B-AA
37
4.5.2
Assignment of the feedback Interface
The user program receives the current values and status information from the technology
module over the feedback interface.
Feedback interface
Table 4- 6 Assignment of the feedback Interface
Charging
outlet
Byte
Bit
Default
Min
Max
Meaning
0 0 0 - 2 0 0 7 ECC State
a)
0: Charging outlet inactive
1: State "A" (no vehicle connected)
2: State "B" (vehicle connected)
3: State "C" (vehicle can be charged; ventilation not re-
quired)
4: State "D" (vehicle can be charged; ventilation required)
5: State "E" (CP conductor short circuit to earth)
6: State "F" (charging station not available)
7: Reserved
3 - 6
0
0
0
System reserve
7 0 0 1 PII -Valid
is set to 1 by the TM ECC 2xPWM ST
1 0 0 0 1 Status of locking requirements
0: Unlocking requested
1: Locking requested
(can be used in a TIA application, for example, when the
locking control is realized outside the module)
1 0 0 1 Status of contactor control
0: Disable requested
1: Enable requested
2 0 0 1 Status of feedback input DI
0: DI = 0
1: DI = 1
3 0 0 1 Validity DI
0: DI value invalid
1: DI value valid
4 0 0 1 Status of ventilation
0: No ventilation required
1: Ventilation required
5 0 0 1 Status of PWM
0: disabled
1: enabled
6 - 7
0
0
0
System reserve
2 - 3
Diagnostics
2
0
0
0
1
CP signal level impermissible
b)
1
0
0
0
System reserve
