Siemens SIMATIC ET 200SP TM ECC 2xPWM ST User Manual

Configuring/address space
4.4 Parameter
Technology module TM ECC 2xPWM ST (6FE1242-6TM10-0BB1)
Manual, 04/2018, A5E42681298B-AA
33
4.4
Parameter
Parameter
You specify the properties of the technology module using various parameters. These can
be assigned by using the HSP or the GSDML file. Depending on the settings, not all
parameters are available. You cannot change the parameter assignment in the user
program.
You have the following options for setting the parameters of the module:
Table 4- 3 Parameter assignment options
Parameter settings using the ...
Basic procedure
Hardware configuration in
STEP 7 with HSP file
1. Install the respective HSP file.
The module is subsequently available in the hardware catalog
under "ET 200SP".
2. Set the device configuration and the parameters in the hard-
ware configuration.
3. Download the parameter assignment to the module.
Hardware configuration with
GSD file for distributed opera-
tion on PROFINET IO
4. Install the latest PROFINET GSD file.
The module is subsequently available in the hardware catalog
under "Additional field devices".
5. Set the parameters of the PROFINET GSD file in the hardware
configuration.
6. Download the parameter assignment to the module.

Siemens SIMATIC ET 200SP TM ECC 2xPWM ST Specifications

General

Category	Control Unit
Manufacturer	Siemens
Series	SIMATIC ET 200SP
Number of PWM Outputs	2
Supply Voltage	24 V DC
Output Current	0.5 A per channel
Short-circuit Protection	Yes
Reverse Polarity Protection	Yes
Number of Channels	2
Output Voltage	24 V DC
Compatible with	SIMATIC ET 200SP system
Resolution	16-bit
Dimensions (W x H x D)	15 mm x 73 mm x 58 mm
Function	PWM (Pulse Width Modulation) control
PWM Frequency Range	0.1 Hz to 1 kHz
