Siemens SIMATIC ET 200SP TM ECC 2xPWM ST User Manual

Technology module TM ECC 2xPWM ST (6FE1242-6TM10-0BB1)
Manual, 04/2018, A5E42681298B-AA
53
Technical specifications
7
7.1
Technical specifications
6FE1242-6TM10-0BB1
General Information
Product brand name SIMATIC
Product family ET 200SP
Product category Technology module
Product type designation
TM ECC 2xPWM ST
Product designation Charging controller for conductive charging of
electric vehicles
Firmware version
V1.0.2
• FW update possible
Yes
Type of product
Technology module
Number of channels
2; according to IEC 61851 and SAE J1772
Product function
I&M data
Yes; I&M 0 to 3
isochronous mode
No
Engineering with
STEP 7 TIA Portal can be configured/integrated
as of version
STEP 7 V14 SP1 and higher
Installation type/mounting
Mounting type
Standard mounting rail
Mounting position
vertical or horizontal
Supply voltage
Voltage type of supply voltage
DC
Rated value (DC)
24 V
Permitted range, low limit (DC)
19.2 V
Permitted range, high limit (DC)
28.8 V
Reverse polarity protection
Yes; against destruction
Input current
Current consumption, typ.
40 mA
Current consumption, max.
90 mA
Digital inputs
Number of inputs
2; 1 per channel
Digital inputs parameterizable
Yes; 12 V/24 V
