Technical specifications
7.1 Technical specifications
Technology module TM ECC 2xPWM ST (6FE1242-6TM10-0BB1)
54 Manual, 04/2018, A5E42681298B-AA
6FE1242-6TM10-0BB1
Functions of digital inputs, parameterizable
Freely usable digital input No, read-back contact contactor / connector
locking
Input voltage
Type of input voltage
DC
For signal "0"
< 0.2x U
nominal
For signal "1"
> 0.6x U
nominal
Permitted voltage at input, min.
0 V
Permitted voltage at input, max.
30 V
Cable length
Unshielded, max.
30 m
Digital outputs
Type of digital output
Transistor
Number of outputs
2; 1 per channel
Short-circuit proof
Yes
Short-circuit protection
Yes; electronic / thermal
Functions of digital outputs, parameterizable
PWM output
Yes; according to IEC 61851 and SAE J1772
• Number, max.
2; 1 per channel
• Time period, parameterizable
No; 1 kHz
Output switching capacity
With resistance load, max.
1.3 A
Output voltage
Type of output voltage DC
Output voltage 24 V
Cable length
Unshielded, max. 30 m
Protocols
Bus communication
Yes
Vehicle communication according to IEC 61851 Yes; MODE 3
Vehicle communication according to SAE J1772
Yes
Interrupts/diagnostics/status information
Interrupts
Diagnostic interrupt
Yes
Diagnostics alarms
Monitoring of supply voltage
Yes
Short circuit
No
Overload
Yes
