Technical specifications
7.1 Technical specifications
Technology module TM ECC 2xPWM ST (6FE1242-6TM10-0BB1)
Manual, 04/2018, A5E42681298B-AA
55
6FE1242-6TM10-0BB1
Diagnostics indicator LED
RUN LED
Yes; green LED
ERROR LED
Yes; red LED
Monitoring of supply voltage
(PWR LED)
Yes; green PWR LED
Channel status display
Yes; green LED
For module diagnostics
Yes; green/red DIAG LED
Galvanic isolation
Galvanic isolation of channels
Between channels
No
Between channels and backplane bus
Yes
Insulation
Insulation test voltage
707 V DC
Degree of pollution
2
EMC
Electrostatic discharge according to IEC 61000-4-2: 2008
Field-based interference according to IEC 61000-4-3: 2006
Conducted interference / due to burst / according to IEC 61000-4-4: 2012
Conducted interference / due to surge / according to IEC 61000-4-5: 2014
Conducted interference / due to high-frequency radiation / according to IEC 61000-4-6: 2013
Degree of protection and protection class
IP degree of protection IP20
Standards, approvals, certificates
Proof of suitability CE
Ambient conditions
Ambient temperature during operation
Minimum
-30 °C
Horizontal mounting position, max.
60 °C
Vertical mounting position, max.
50 °C
Ambient temperature during storage/transport
Storage, min.
-40 °C
Storage, max.
70 °C
Transport, min.
-40 °C
Transport, max.
70 °C
Relative humidity
Operation, min.
5%
Operation, max.
95%, no condensation
Extended range of ambient conditions
with reference to ambient temperature, air pres-
sure and altitude
T
min
... T
max
at 1080 hPa ... 795 hPa
(-1000 m ... +2000 m)
