17-8
OP27,
OP37 Equipment Manual
Release 05/99
Use
transparent foil to make labeling strips so that the LEDs in the function
keys remain visible. Use a printer or a smudge-proof foil pen to label the foil.
Cut the strips as illustrated in the examples in Figure 17-5.
Figure 17-6 Dimensions of Labeling Strips for OP37
Included
with the ProT
ool configuration software is the W
ord
file
SLIDE_37.DOC
. The file contains formatted samples for labeling the func
-
tion keys on the OP37. This means labeling strips can be individually edited
and printed.
Make labeling
strips
File
OP37 Unit Description
