8-16
OP27,
OP37 Equipment Manual
Release 05/99
A
record set can be created in standard screen Data Recor
d Pr
ocessing
in two
dif
ferent ways, i.e. saved on a data medium:
1. Save a data r
ecord for each r
ecipe
Step Action
1 Select RecordSet as the recipe.
2 Define the data record name and the data medium.
3 Save the record set as with a data record.
A data record is created for each recipe.
4 Delete any data records not required.
2.
Save a data r
ecord individually for selected r
ecipes
Step Action
1 Select the recipe name, e.g. ORANGE.
2 Define the data record name (e.g. Drink) and data medium. Each data
record name must be created with the same name (= Drink).
3 Edit the data record and save it.
4 Repeat steps 1 and 3 for each data record.
During
the loading procedure all the data records with the selected name
located on the data medium are loaded in the main memory of the OP and
transferred on to the PLC. The sequence of steps corresponds to the procedure
described on Page 8-12 under
Loading data r
ecords.
Note
It may take a relatively long time to upload a record set from the data
medium to the PLC, depending on the size of the recipes. A record set
should, therefore, only contain essential recipes.
During the following downloading procedure,
all
current values of
all
recipe tags are transferred, and not just the data records with the same
name:
–
PLC
³
OP
– PLC
³ Data
medium
–
OP
³ PLC
Save
(Create)
Load
Recipes
