Operating a project
8.2 Operating a project on TP 177micro
OP 73micro, TP 177micro (WinCC flexible)
Operating Instructions, 09/2007, 6AV6691-1DF01-0AB0
123
8.2.3.6 Viewing infotext
Purpose
The configuration engineer uses infotext to provide additional information and operating
instructions with respect to screens and operable screen objects.
Infotext can provide information on the value to be entered in an IO field, for example.
Figure 8-7 Infotext for an IO field, example
Infotext for input objects
Touch the key on the screen keyboard. This key is only enabled if infotext has been
configured for the input object.
Infotext for the current screen
The configuration engineer can also provide infotext for screens. However, the infotext for
the current screen is called up by an operator control object assigned to this function and not
by the screen keyboard.
Further information on this may be available in your plant documentation.
Closing the infotext
Close the infotext with .
