OP 73micro, TP 177micro (WinCC flexible)
Operating Instructions, 09/2007, 6AV6691-1DF01-0AB0
27
Planning use
3
3.1 Mounting information
Mechanical and climatic conditions of use
The HMI device is intended for installation in weatherproof permanent locations. The
conditions of use are compliant with requirements to DIN IEC 60721-3-3:
● Class 3M3 (mechanical requirements)
● Class 3K3 (climatic requirements)
Use with additional measures
Examples of applications where the use of the HMI device requires additional measures:
● In locations with a high degree of ionizing radiation
● In locations with extreme operating conditions resulting from situations as follows:
– Corrosive vapors, gases, oils or chemicals
– Electrical or magnetic fields of high intensity
● In plants requiring special monitoring features, for example:
– Elevator systems
– Systems in especially hazardous rooms
Mechanical ambient conditions
The mechanical ambient conditions for the HMI device are specified in the following table in
terms of sinusoidal vibration.
Table 3-1 Mechanical ambient conditions
Frequency range
in Hz
Continuous Occasional
10 ≤ f ≤ 58 Amplitude 0.0375 mm Amplitude 0.075 mm
58 ≤ f ≤ 150 0.5 g constant acceleration Constant acceleration 1 g
