Configuring the operating system
6.1 Configuring the operating system for the OP 73micro
OP 73micro, TP 177micro (WinCC flexible)
72 Operating Instructions, 09/2007, 6AV6691-1DF01-0AB0
Editing dialog entries
Button Action
+/–
or
TAB
Selects the previous or next list entry.
ENTER
The selected list entry is accepted.
ESC
HELP
You can undo your input as long you have not yet confirmed the
selected list entry with
ENTER
.
See also
Switching on power and testing the HMI device (Page 46)
6.1.2 "Info/Settings" menu
6.1.2.1 Overview
Requirements
"Info/Settings" was called in the Loader.
"Info/Settings" menu
Info/Settings
Device Info
Contrast
Logon/Settings
Version Info
Figure 6-2 "Info/Settings" menu
"Contrast" Menu command for setting the display contrast
"Device Info" Menu command with information on the HMI device
"Version Info" Menu command with information on the version of the HMI device image
"Logon/Settings" Menu command of the "Logon/Settings" menu
