Specifications
11.1 Dimensional drawings
OP 73micro, TP 177micro (WinCC flexible)
142 Operating Instructions, 09/2007, 6AV6691-1DF01-0AB0
11.1.2 Dimensional drawings, TP 177micro
212
6.2
140
156
196
44
Figure 11-2 Overall dimensions of the HMI device
