Configuring the operating system
6.1 Configuring the operating system for the OP 73micro
OP 73micro, TP 177micro (WinCC flexible)
Operating Instructions, 09/2007, 6AV6691-1DF01-0AB0
75
6.1.2.4 Viewing information about the version of the HMI device image
Requirements
"Info/Settings ▶ Version Info" was selected from the Loader menu.
Principle
Version Info
BL 0.17/2004-xx-xx
01.00.00.00_05.08
Figure 6-6 "Version Info" dialog – Example
The "Version Info" dialog shows information on the Bootloader and the HMI device image file
and therefore the version of the operating system.
This information is required when you contact A&D Technical Support.
6.1.3 "Settings" menu
6.1.3.1 Overview
Requirement
"Info/Settings ▶ Logon/Settings" was selected from the Loader menu. You have entered the
password for the "Settings" menu.
"Settings" menu
Settings
Startup Delay
Screensaver
---------------
Figure 6-7 "Settings" menu
"Startup Delay" Menu command for setting the startup delay on the HMI device
"Screen Saver" Menu command for the screen saver
"Password" Menu command for the password
"Transfer Settings" Menu command for transfer settings
Select the "Settings" menu to edit the system settings for your HMI device.
Access to this menu can be protected by a password.
