Button Display
Fault/Alarm This button calls the detailed fault and alarm messages of the converter.
Local operation This button controls the local operation of the converter. The following functions are
available:
● Speed controlled
● Parameters
● Expert
3.3 Color information
Additional information is displayed for some functions in the form of color fields. The color fields
have the following meanings:
Figure 3-4 Color information
Description
3.3 Color information
TP900 Function Manual
Function Manual, 10/2016, A5E39487277A 15
