Getting Started - ET 200S-IM 151/CPU Interface Module

A5E00058783-01

8-2

0DWHULDOVDQG7RROV5HTXLUHG

4XDQWLW\ ,WHP 2UGHU1XPEHU6,(0(16

1 S7-300 system, consisting of power supply (PS), CPU with

DP interface(CPU 315 2-DP in this example), digital input

module (DI) on slot 4 and digital output module (DO) on

slot 5, incl. bus connector and cabling

Various

1 Power supply (PS), e.g. PS 307 with network connecting

cable (optional)

e.g. 6ES7 307-1EA00-0AA0

1 IM 151/CPU with terminating module e.g. 6ES7 151-7AA00-0AB0

1 Power module (PM) e.g. 6ES7 138-4CA00-0AA0

1 Digital input module (DI) e.g. 6ES7 131-4BD00-0AA0

1 Digital output module (DO) e.g. 6ES7 132-4BD00-0AA0

1 Terminal module (TM) for the PM e.g. 6ES7 193-4CC30-0AA0

2 Terminal modules (TM) for DI and DO e.g. 6ES7 193-4CB30-0AA0

1 Rail for ET 200S Various

1 Programming device (PG) with PROFIBUS-DP interface,

installed STEP 7 software, version  5.1

and PG cable (up to 1.5 Mbps)

Various

1 PROFIBUS-DP cable Various

1 Screwdriver with 3 mm blade Standard

1 Screwdriver with 4.5 mm blade Standard

1 Diagonal cutter and tool for insulation stripping Standard

1 Tool for pressing on wire-end ferrules Standard

Approx.

Stranded wire with 1 mm

cross-section with correct wire

end ferrules (type A, length 6 mm and 12 mm)

Standard

4 1-pin on switch (24 V) Standard
