Siemens SIMATIC IM 151/CPU User Manual

*HWWLQJ6WDUWHG
Getting Started - ET 200S-IM 151/CPU Interface Module
A5E00058783-01
8-8
6WHS3URJUDPPLQJWKH,0&38
6WHS 3URFHGXUH 5HVXOW
1
Navigate in SIMATIC Manager via ,0&38 and
63URJUDP to the %ORFNVcontainer.
2
Double-click the 2% icon in the right-hand part of
the window.
The LAD/FBD/STL editor for editing
the OB1 block opens.
3
In the LAD/FBD/STL editor, choose the /$'
command from the 9LHZmenu to switch to the LAD
programming language.
A rung current path is displayed in
network 1.
4 Click exactly on the horizontal line of the rung current
path.
The line is highlighted.
5 Double-click the -||- button (normally open contact)
on the toolbar, and then click the –( ) button (coil).
The icons are inserted into the rung
current path.
6 Click the red question mark of the normally open
contact on the left in the rung current path.
The normally open contact is
highlighted, and a text box with a
cursor appears at the point of the
question mark.
7
Enter
,and press 5HWXUQ
The normally open contact on the left
is assigned the designation ,
8
Enter
, press 5HWXUQ
Enter4 and press 5HWXUQ
The normally open contact on the left
is assigned the designation ,.
The coil is assigned the designation
4
9 Close the editor and confirm that you want to save
with <HV.
The editor is closed, and the OB1 is
saved.
