Siemens SIMATIC IM151-1 STANDARD User Manual

Interface module IM151-1 STANDARD (6ES7151-1AA06-0AB0)
12 Manual, 07/2015, A5E01075950-AD
Parameters
2
2.1
Parameters for the IM151-1 STANDARD interface module
Table 2- 1 Parameters for the IM151-1 STANDARD interface module
IM151-1 STANDARD
Range of values
Default setting
5
Applicability
DP interrupt mode DPV0/DPV1 DPV0 ET 200S
Bus length
≤ 1 m/> 1 m
≤ 1 m
ET 200S
Operation at set < > actual
configuration
1
Disable/enable Disable ET 200S
Diagnostic interrupt
3
Disable/enable
Disable
ET 200S
Process interrupt
3
Disable/enable
Disable
ET 200S
Remove/insert module inter-
rupt
2 3
Disable/enable Disable ET 200S
Identifier-related diagnostics
Disable/enable
Enable
ET 200S
Module status
Disable/enable
Enable
ET 200S
Channel-specific diagnostics
Disable/enable
Enable
ET 200S
Option handling in general
Disable/enable
Disable
ET 200S
Option handling with / without reserve
module
with reserve mod-
ule
ET 200S
Option handling:
Slots 2 to 63
Disable/enable Disable ET 200S
Analog value format
4
SIMATIC S7/
SIMATIC S5
S7 ET 200S
Interference frequency sup-
pression
50 Hz/60 Hz 50 Hz ET 200S
Reference junction slot
None /2 to 63
None
ET 200S
Reference junction input RTD on channel 0/
RTD on channel 1
0 ET 200S
1
See also the "option handling" parameter.
2
The default setting of the parameter in the GSD file is "disable".
3
Only parameterizable in DPV1 operation.
4
The parameter only exists when configuring via the GSD file.
5
The default settings apply to the default startup (if no other parameters have been assigned by the
DP master).
