Siemens SIMATIC IM151-1 STANDARD User Manual

Functions
3.2 Option handling without reserve modules
Interface module IM151-1 STANDARD (6ES7151-1AA06-0AB0)
Manual, 07/2015, A5E01075950-AD
29
3.2.4
63B
Configuring option handling without RESERVE modules
Introduction
You configure option handling without RESERVE modules as described below.
Procedure
1. Drag a PM-E 24..48 VDC or PM-E 24..48 VDC/24..230 VAC power module with one of
the following entries into the configuration table:
– ...O (option handling) or
– ...SO (status byte + option handling)
Note
You may only enter the power module with the ending ...O or ...SO once
in the
ET
200S configuration! We recommend configuring the power module to slot 1.
2. Assign parameters to the interface module as follows:
Interface module
Parameter
Setting
Description
IM151-1
STANDARD
(6ES7151-1AA05-
0AB0 or higher)
Option handling,
general
Enable Option handling is activated for
the entire ET 200S.
Option handling:
With/without
RESERVE mod-
ules
Without RESERVE
modules
Selects option handling without
RESERVE modules
Note
If "Operation for set < > actual installation" is blocked f
or parameter assignment, the
ET
200S does not start up if a module is missing or if an incorrect module is pl
ugged in. If an
incorrect module is inserted, then the ET 200S will function but the I/O will not be enabled.
The diagnostic "No module" or "Incorrect module" is signaled.
If the IM151
-1 does not start up in this state, the SF LED lights up at the IM151-1 and at the
deactivated electronic module of the ET 200S.
