Functions
3.3 Identification data
Interface module IM151-1 STANDARD (6ES7151-1AA06-0AB0)
Manual, 07/2015, A5E01075950-AD
35
Reading of identification data
Table 3- 9 Identification data
Identification data
Access
Default setting
Description
Identification data 0: Index 1 (Data record 231)
MANUFACTURER_ID read (2 Byte) 2A hex (= 42 dec) The name of the manufacturer is stored
here. (42 dec = SIEMENS AG)
ORDER_ID Read (20 bytes) Depends on the mod-
ule
Order number of the module
SERIAL_NUMBER
Read (16 bytes)
Not relevant
HARDWARE_REVISION
read (2 Byte)
Not relevant
SOFTWARE_REVISION Read (4 bytes) Firmware version This indicates the firmware version of the
module.
REVISION_COUNTER read (2 Byte) - Provides information on parameter modifi-
cations on the module.
PROFILE_ID
read (2 Byte)
F600 hex
Generic Device
PROFILE_SPECIFIC_TYPE read (2 Byte) 0003 hex
0005 hex
On electronic modules
on interface modules
IM_VERSION read (2 Byte) 0101 hex Provides information on the ID data version
(0101 hex = version 1.1)
IM_SUPPORTED read (2 Byte) 000E hex Provides information on existing identifica-
tion data (index 2 to 4)
Maintenance data 1: Index 2 (Data record 232)
TAG_FUNCTION Read/write (32
bytes)
- Define a unique identifier for the module in
this record.
TAG_LOCATION Read/write (22
bytes)
- Enter the installation location of the module
here.
Maintenance data 2: Index 3 (data record 233)
INSTALLATION_DATE Read/write (16
bytes)
- Enter the installation date of the module
here.
RESERVED Read/write (38
bytes)
- Reserved
Maintenance data 3: Index 4 (data record 234)
DESCRIPTOR Read/write (54
bytes)
- Enter a comment on the module here.
