Technical specifications
8.5 Technical specifications
SIMATIC IPC427D
Operating Instructions, 05/2017, A5E31347215-AB
117
RS232, 115 kbps max., 9-pin SUB-D, male
Connection of display devices with DVI connector
Connection of display devices with DPP connector
Mouse USB support
USB 4 × USB 3.0, a maximum of 2 can be operated in high-current
PROFIBUS / MPI interface, iso-
lated
- Transmission speed
9-pin Cannon socket, 2-row
9.6 kbps to 12 Mbps
DP master: DP-V0, DP-V1 with SOFTNET-DP
DP slave: DP-V0, DP-V1 with SOFTNET-DP slave
PROFINET 3 × RJ45 connector, CP1616 compatible, on-board interface on
ERTEC 400 basis, 10/100 Mbps electrically isolated
Ethernet
3
2 × Ethernet port (RJ45) Intel 82579LM and Intel 82574L
10/100/1000 Mbps, electrically isolated, teaming-capable
4
or 1 x Ethernet port for PROFINET device
Free slots for expansion cards
Up to 2 × PCIe cards, depending on enclosure version
For unique labeling, the Ethernet ports are numbered on the enclosure. The numbering by the
operating system can differ.
