Device maintenance and repair
7.3 Installing and removing hardware
SIMATIC IPC427D
90 Operating Instructions, 05/2017, A5E31347215-AB
7.3.2.2
Installing a memory card fitting
A memory card fitting for a second CFast memory card is available for the device. You can
install the memory card rack instead of the HDD or SSD.
The type of memory card to be used is described in "Installing and removing CFast cards
(Page 76)."
Requirement
● The device is disconnected from the power supply.
● The device is removed.
● 1 T10 screwdriver
Procedure
Removal
1.
Remove the screws shown.
Push off the cover in the direction ind
i-
c
ated and lift it off.
2.
Remove the screws shown.
3.
Remove the HDD or SSD from the encl
o-
sure.
