Technical specifications
9.5 Hardware descriptions
SIMATIC IPC477E PRO
132 Operating Instructions, 08/2017, A5E39912462-AA
Interrupt
Interrupt type
IRQ9
ACPI-SCI (system control interrupt)
IRQ10 Free
IRQ11
Free
IRQ12 Free
IRQ13
Numeric data processor
ISA exclusive
IRQ14
Free
IRQ15
Free
IRQ16 High Definition Audio Controller
SATA AHCI Controller
LAN1 (I219-LM)
Graphics Management Engine Interface
USB XHCI Controller
PCI shared
IRQ17
PCIe-x4 slot on Riser (1x4)
PCI exclusive
IRQ18 PCIe-x4 slot on Riser
LAN2 (I210)
PCI shared
IRQ19
LAN3 (I210) (optional)
PCI exclusive
IRQ20
Free
IRQ21
Free
IRQ22
Free
IRQ23
Free
