Expanding the device and assigning the device parameters
7.2 Installing and removing a memory module
SIMATIC IPC477E PRO
80 Operating Instructions, 08/2017, A5E39912462-AA
Insert the memory module into the
marked slot at an incline with the contact
side toward the motherboard.
Carefully press the memory
module into
the contact strip until the latches engage.
