SIMATIC MV320 / SIMATIC MV325
Operating Instructions, 08/2015, C79000-G8976-C352-03
39
Alarm, error and system messages
7
7.1
Feedback from the reader
Table 7- 1 SIMATIC MV320
Situation
LED displays on the
reader
Acoustic signal
Vibration signal
SIMATIC MV320 is turned on. Green LED flashes 1x
Successful establishment of the con-
nection between SIMATIC MV320 and
the host (by cable).
Green LED goes off
after connection
establishment
1x
Decoding attempt active. Green LED is off -- --
Decoding and data transfer successful.
Green LED flashes
1x
Configuration code successfully
decoded and processed.
Green LED flashes 2x
Configuration code successfully
decoded but not successfully
processed.
Green LED flashes 4x
Table 7- 2 SIMATIC MV325
Situation
LED displays on the
reader
Acoustic signal
Vibration signal
SIMATIC MV325 turned on
successfully.
All LEDs flash 1x
SIMATIC MV325 connected to host
successfully.
Wireless symbol
flashes
1x
SIMATIC MV325 not connected to host
successfully.
-- 3x --
Decoding and data transfer successful.
Read display flashes
1x
Decoding and data transfer not
successful.
-- 3x --
Configuration code successfully
decoded and processed.
Read display flashes 2x
Configuration code not successfully
decoded and processed.
-- 4x --
Batch mode enabled and no data
stored
Batch symbol off -- --
Batch mode enabled and data stored. Batch symbol flash-
ing
-- --
