Technical data
SIMATIC MV320 / SIMATIC MV325
46 Operating Instructions, 08/2015, C79000-G8976-C352-03
• Near field
30° x 20° (horizontal x vertical)
• Wide field
50° x 33.5° (horizontal x vertical)
CMOS 1.2 megapixels (1280 x 960) gray shades
• Near field
960 x 640
• Wide field
960 x 640
±60° (from front to rear)
± 60° level parallel to symbol (between sides)
Print contrast resolution 25% (1D codes) or 35% (2D codes) absolute
dark/light reflectance differential measured at
Single, blue target strip
128 MB flash ROM / 32 MB RAM
USB 2.0 (generic, keyboard, virtual COM port)
Communications interfaces
Bluetooth (Class II)
Dimensions, H x L x W in mm
• Reader
135 x 130 x 51
• Charging station
60 x 115 x 83
• Reader
0.171 kg
• Battery
0.48 kg
• Charging station with integrated Bluetooth
modem
0.153 kg
