Cellular Modem Modules
6.5RUGGEDCOM RX1500PN LM W32
Note
If this module is integrated into a portable device, separate approval related to the
Specific Absorption Rate (SAR) requirements of FCC Part 2.1093 and IC RSS-102 is
required.
• Persons in the area must be kept at least 20 cm (8 in) from the antenna at all
times.
• The antenna gain, including cable loss, must not exceed the maximum allowable
gain specified for the module.
• The cellular modem and antenna must not be next to or operate in conjunction
with another transmitter or antenna within a host device.
• A label must be affixed to the end product that indicates the FCC and Industry
Canada IDs for the cellular modem.
• The user documentation for the end product must clearly indicate the operating
requirements and conditions that comply with current FCC and IC radio
frequency exposure guidelines.
• The end product must comply with the unintentional emission testing
requirements of FCC Part 15.
If the application does not meet these requirements, further certification is required.
Installing the Module
To install the module, do the following:
1. Open the module and install a mini-SIM card for each network carrier.
2. Insert the module into the host device. For more information, refer to the
Installation Manual for the device.
3. Connect antennas.
Installing SIM Cards
The line module requires at least one active mini-SIM card (2FF size format) for the
primary antenna to connect with the associated network carrier. A second SIM card
can be installed for redundancy if needed.
To install one or more SIM cards, do the following:
NOTICE
Static electricity hazard – risk of damage to equipment
Make sure to take appropriate anti-static precautions before opening the cellular
modem module.
Note
The module only supports mini-SIM cards (2FF size format).
142
RUGGEDCOM Modules
Catalog, 07/2021, C79000-G8976-1320-16
