Hardware Overview
1-9
SIMATIC PCS 7 OSx 4.0.0 Hardware (PA RISC)
1.4 Equipment Physical Dimensions
T able 1-3 lists external physical dimensions for individual OSx station
subassemblies. Allow sufficient space so that power and signal cables can be
attached to the rear of the system unit and monitor .
Table 1-3 PA RISC Physical Dimensions
Subassembly Height Depth Width
System Unit (Model B132L+)
17.75 in.
45.08cm
18.0 in.
45.72 cm
4.5 in.
1 1.43 cm
Monitor (21-in; includes base assembly)
19.0 in.
48.5 cm
21.0 in.
53.8 cm
19.6 in.
49.8 cm
Monitor (17-in; includes base assembly)
16.5 in.
41.0 cm
16.5 in.
42.0 cm
16.1 1 in.
42.0 cm
Operator Keyboard
2.5 in.
6.3 cm
10.25 in.
26.0 cm
17.12 in.
43.5 cm
Engineering Keyboard
2.0 in.
5.1 cm
8.0 in.
20.3 cm
18.5 in.
47.0 cm
Trackball
3.0 in.
7.6 cm
7.75 in.
19.7 cm
4.38 in.
1 1.1 cm
Trackball
3.0 in.
7.6 cm
7.75 in.
19.7 cm
4.38 in.
1 1.1 cm
Magneto-Optical Drive
4.0 in.
10.2 cm
13.0 in.
33.0 cm
6.5 in.
16.5 cm
Magneto-Optical Drive
4.0 in.
10.2 cm
13.0 in.
33.0 cm
6.5 in.
16.5 cm
When figuring the total space that is required for individual subassemblies,
consider the following.
• The physical dimensions for individual subassemblies do not account
for cabling. Allow sufficient space so that power and signal cables can
be attached to the rear of the system unit and monitor .
• The system unit has fans mounted inside the box to provide adequate
air circulation. Be sure to provide a minimum of two inches free air
space adjacent to all system unit fan openings.
• There are several openings at the top and at the rear of the monitor
cabinet for cooling purposes. Plan for enough space around the monitor
cabinet (two inches minimum) to provide adequate cooling.
Subassembly
Dimensions
 

