Hardware Overview
1-19
SIMATIC PCS 7 OSx 4.0.0 Hardware (PA RISC)
If
you do not have an operator keyboard, you can connect the engineering
keyboard and a pointing device directly to the system unit.
Figure 1-4
shows
cable connections.
Pointing
Device
Engineering
Keyboard
12
Figure 1-4 Installing the Engineering Keyboard
Installing the
Engineering
Keyboard
