Hardware Overview
1-10
SIMATIC PCS 7 OSx 4.0.0 Hardware (PA RISC)
1.5 Power Requirements
T able 1-4 lists specific power requirements for your system.
Table 1-4 Power Specifications
Subassembly Voltage Frequency Power Consumption Current
System Unit
(Model B132L+)
100–120 V AC or
220–240 V AC
(Automatic)
50–60 Hertz 300 W atts maximum
5.0 Amperes
(100–120 V AC)
3.0 Amperes
(220–240 V AC)
Monitor (21-inch) 90–270 V AC 47–63 Hertz
75 W atts
(120 W maximum)
1.2 Amperes
Monitor (17-inch) 100–240 V AC 50–60 Hertz 80 W atts 1.9 Amperes
Magneto-Optical Drive 100–240 V AC 50–60 Hertz N/A 0.8–0.5 Amperes
Power Supply
Specifications
