Working with S5-DOS/ST
C79000-G8576-C760-03
The V.24/TTY converter is connected between the PC with a V.24
port and the PLC. The port on the PC (male or female connector,
9-pin or 25-pin) should be stated when ordering the box. The
second port corresponds to the normal PLC output of the S5
programming devices, so that existing PLC connecting cables can
be plugged in directly.
V.24/TTY converter 224 221
and, as required:
Connecting cable type 1 224 221
(COM 1 of the PC is a 9-pin male connector)
Connecting cable type 2 224 222
(COM 1 of the PC is a 9-way female connector)
Connecting cable type 3 224 223
(COM 1 of the PC is a 25-pin male connector)
Connecting cable type 4 224 224
(COM 1 of the PC is a 25-way female connector)5.
Operating voltage:
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
115/230 VAC + /- 10%, selectable
Secondary voltage:
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
+ /- 12 V, electrically isolated
Fuse:
2 x 5000 mA (medium blow)
Ambient temperature:
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
0 to 45
o
C (32 to 113
o
F)
Mains frequency:
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
48 to 63 Hz
Power input:
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
max. 5 VA
TTY current:
20/50 mA selectable with jumpers
Dimensions:
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
(WxHxD) 138 x 46 x 195 mm
Weight:
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
approx. 750 g incl. power cable
Connecting cable:
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
approx. 2 m (ground-protected
connector)
PC connection:
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
9-pin male connector (V.24 serial)
ÁÁÁÁÁÁÁ
PLC connection:
ÁÁÁÁÁÁÁÁÁÁÁÁÁ
25-pin female connector with
slide-in connection
Indicators:
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
2 LEDs for RxD and TxD
Connection
Order Nos.
Technical Data
V.24/TTY Converter
