The following figure shows a configuration of the S7-1500H in a PROFINET ring.












352),1(7
,QGXVWULDO(WKHUQHW
① H-CPU
② PROFINET cable (PROFINET ring)
③ Redundancy connections (fiber-optic cables)
④ IO device
⑤ Switch
Figure 4-5S7-1500H configuration with IO devices in the PROFINET ring
28
S7-1500R/H redundant system
System Manual, 11/2022, A5E41814787-AD
System overview
4.1 What is the S7-1500R/H redundant system?
