Siemens Simatic S7-1500R - Page 313

Color and icons for the status
data
Meaning
Orange • STARTUP
• SYNCUP
• STOP
• STOP - firmware update
Red FAULT
White • Connection established between CPU and display.
Protection level configured.
• At least one alarm is active in the CPU.
• No SIMATIC memory card inserted in the CPU.
• No user program loaded.
Force job is active in the CPU.
F-capability activated. Safety mode active. The symbol is grayed out when safety mode is
deactivated.
Fail-safe CPU
Regarding ②: Names of the menus
The following table shows the available menus of the display.
Table 12-2Names of the menus
Main menu items Meaning Description
Overview The "Overview" menu contains information about:
• Properties of the local CPU
• Properties of the F-CPU
– Status of the safety mode
– Collective signature
– Date of the last changes
• Redundancy properties, for example
– Display of role (primary CPU or backup CPU)
– Displaying and setting the redundancy ID
– Display of the pairing state
• Properties of the inserted SIMATIC memory card
Diagnostics The "Diagnostics" menu includes:
• Display of alarms
• Display of the diagnostics buffer
• Read and write access to force and watch tables
• Display of cycle time
• Display of memory used
313
Display
12.1 CPU display
S7-1500R/H redundant system
System Manual, 11/2022, A5E41814787-AD
