Main menu items Meaning Description
Settings In the "Settings" menu you:
• Assign IP address and PROFINET device name of the CPU
• Setting date/time
• Set operating states (RUN/STOP)
• Perform a CPU memory reset or reset to factory settings
• Disabling and enabling passwords
• Disable/enable display with display password
• Format SIMATIC memory card
• Run firmware update and display status
• Convert SIMATIC memory card or delete user program
Modules The "Modules" menu is not supported for R/H-CPUs.
Display In the "Display" menu you can configure settings related to the display, such
as language setting, brightness and energy-saving mode. The energy-saving
mode dims the display. Standby mode switches off the display.
Menu icons
The following table shows the icons that are displayed in the menus.
Table 12-3Menu icons
Icon Meaning
Editable menu item.
Select the required language.
A message is available in the next lower level page.
There is an error in the next lower level page.
The marked module is not accessible.
Navigate to the next lower level page.
In edit mode you make the selection using two arrow keys:
• Down/up: Jumps to the selection or is used to select the desired digits/options.
In edit mode you make the selection using four arrow keys:
• Down/up: Jumps to the selection or is used to select the desired digits.
• Left/right: Jumps one place forward or back.
The alarm is not yet acknowledged.
The alarm is acknowledged.
314
S7-1500R/H redundant system
System Manual, 11/2022, A5E41814787-AD
Display
12.1 CPU display
